S3003 Servo Motor – 360 Degree
$7.90
Description
This servo features plastic gears with its 360° continuous rotation. It is capable of producing moderate torque (about 3.2 kg·cm at 4.8V and 4.1 kg·cm at 6.0V), which makes it suitable for light to medium-duty mechanical tasks. Its lightweight and compact design allows for easy integration into various projects.
It operates on a voltage range of 4.8V to 6.0V, compatible with most microcontrollers including Arduino, Raspberry Pi, and ESP32. The S3003 includes a 3-wire cable for signal, power, and ground, making it easy to connect and control.
Specifications
| Specification | Details |
|---|---|
| Model: | S3003 |
| Rotation Angle: | 360° |
| Control Signal: | PWM (Pulse Width Modulation) |
| Operating Voltage: | 4.8V – 6.0V |
| Torque @ 4.8V: | ~3.2 kg·cm |
| Torque @ 6.0V: | ~4.1 kg·cm |
| Speed @ 4.8V: | ~0.23 sec/60° |
| Speed @ 6.0V: | ~0.19 sec/60° |
| Motor Type: | 3-pole motor |
| Gear Material: | Plastic gears |
| Bearings: | None (bushing type) |
| Connector Type: | 3-pin standard servo plug (Signal, VCC, GND) |
Packaging List
- x1 unit S3003 Servo motor.
- x4 sets Arms/horns for various interface applications.
- x5 sets Screws for mounting.
- x4 sets Rubber and brass bushings for mounting.
